Application: liquid level measurement of liquid with low dielectric constant or surface fluctuation and complex structure in the tank
Maximum range: 6m
Process connection:thread, flange
Process temperature: : -40~250℃
Process pressure: -0.1~4.0Mpa
Accuracy: ±3mm
Frequency range: 100MHz~1.8GHz
Signal output:
4~20mA/HART 24V DC 2-wire /4-wire system;
4~20mA/HART 220V AC 4-wire system；
RS485/Modbus
Explosion-proof grade: Exia IIC T6 Ga；Exd IIC T6 Gb
Protection class: IP68
